Mixing - Grinding - Blending
Outstanding Toll Processing Services
Powder Processing & Technology provides the equipment, facility, and manpower for complete powder toll processing, including wet grinding, toll milling, and toll classification. We have the ability to pelletize powders, mill down pellets to powders, mill powders down to 0.5 µm in size, and batch and blend various sized powder quantities.
PPT can also batch, blend and classify materials to your requirements. All toll processing operations performed at our ISO 9001:2008 facility are fully documented and are overseen by our team of materials engineers. Depending on the size and complexity of the processing job, turnaround times for powder processing can be as short as one week.
Batches and blended powders can be stored or inventoried at our facility if necessary or we can provide a variety of shipping options including drop-shipping or third-party shipping.
Our in-house laboratory provides analytical testing capabilities for various powder properties, including moisture content, size distribution, contamination level, pH level, magnetic levels, and green strength. We will provide a certificate of analysis for all testing upon customer request.
Call us today for more information.
Vast Variety of Toll Processing Services
Call us today for more information.
219-462-4141
Complementary Processing Capabilities:
Powder Processing & Technology offers a variety of toll processing services for ceramic and inorganic powders.
Our facility is equipped for:
- Pelletizing
- Wet grinding
- Dry grinding
- Milling
- Wet/dry batching
- Lot blending
- V blending
- Double cone blending
- Ribbon blending
- Classification
Grinding Equipment
-
Dry Grinding (Palla Rod Mill)List Item 1
- Particle size capabilities down to 1 micron
-
Hammer Mill (Prater)List Item 2
- De-agglomeration (Sizes up 2"x4"x4") depending on material hardness
-
Hammer Mill (Jacobson)
- To be used after Prater mill for finer de-agglomeration
-
Vibratory Mill (Sweco)
- Cylindrical shaped steel grinding media
- Approximately 227 kg product capacity (depends on density)
-
Wet Ball Milling
- Hardened alloy spherical steel grinding media
- Load capacity of 454 kg - 11,340 kg
1 mill at 454 kg capacity
1 mill at 1,815 kg capacity
7 mills at 2,268 kg capacity
1 mill at 11,340 kg capacity
- Ceramic Ball Mills with high alumina spherical grinding media
6 mills at 3,000 liter capacity
-
Wet Attrition Milling (Union Process Q-50)
- Recirculating Batch attrition
- Used for fine grinding
- Spherical Chrome alloy grinding media
- Load capacity of 907 kg - 3,175 kg
- 1,893 liters hold tank for continuous attrition
- 2 mills available
Powder Classification Equipment
-
20' Niro Spray DryerList Item 1
- Slurry feed to nozzles or wheel atomizer
- 1 to 5 nozzles capability
- 1000 psi maximum pump pressure capability with nozzles
- Wheel atomization capability
- 12,500 wheel RPM maximum
-
48" Sweco Screeners (single and double deck)
- 4 Mesh through 325 Mesh screening capability
-
30" Sweco Screeners (single deck)
- 4 Mesh through 325 Mesh screening capability
-
Separator - Magnetic Separator
- Magnetic separation of powders
